Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity

Categories Compression Test Machine
Brand Name: Infinity Machine
Model Number: RS-8000A
Certification: CE, ISO
Place of Origin: Made in China
MOQ: 1
Price: Negotiable
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
Delivery Time: Shipped in 15 days after payment
Packaging Details: Standard export wooden case with operation manual and video inside.
Max. capacity: 300KN
Max. stroke: 800mm
Effective width: 400mm / 600mm
Load resolution: 1/500,000
Load accuracy: ±0.25%
Weight: 1500 Kg
Dimension: 1220x720x2200mm
Power Supply: AC220V 15A or specified by user
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
  • Submit Buying Request
    • Product Details
    • Company Profile

    Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity


    Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity


    Model: RS-8000A


    Purpose:


    This compressive strength testing machine is suitable for adhesive tape, rubber, plastic, sponge, waterproof materials, electric wire & cable, textile, net rope, non-woven fabrics etc, nonmetal materials and metallic thread, metal foil, steel plate and metal rod to do tensile, compression, bending, peeling, cutting, tearing shearing tests.

    It is used for spot test in production line, can do many data analysis and print the test report, also can used for material’s cyclic test and holding test.


    Features:


    High accuracy:

    Adopt AC servo motor to driving the high precise ball screw working, with high precise explosion-proof load cell. Strength accuracy reached to ±0.25% & displacement accuracy reach to 0.001mm.



    Superior software program:

    Can achieve the closed loop control in force value, speed & displacement, so can satisfy the fatigue test of rubber and durable test of other material in the condition of low cycle. Can record and memorize the whole testing data. And also had many kinds of analysis curve: stress vs strain curve, strength vs deformation curve, strength vs displacement curve, strength vs time curve, time vs deformation curve.


    Multi-function:

    Can coordinate with different grips, the tests of tensile, compression, bending, shearing, tearing, peeling, etc can be done.


    Specification:


    ModelRS-8000A
    Capacity (optional)100KN, 200KN, 300KN
    Unit (switchable)N, KN, Kgf, Lbf, Mpa, Lbf/In2, Kgf/mm2
    Load resolution1/500,000
    Load accuracy±0.25%
    Load rangeRangless
    Stroke (exclude the grips)650mm, 800mm (optional)
    Effective width400mm , 600mm (optional)
    Test speed0.001~300mm/min
    Speed accuracy±0.5%
    Displacement resolution0.001mm
    SoftwareClosed-loop control software
    MotorAC servo Motor
    Transmission rodHigh accuracy ball screw
    Main unit dimension (WxDxH)1220x720x2200mm
    Main unit weight1500 Kg
    Power SupplyAC220V 15A or specified by user

    Picture:



    Cheap Concrete Compressive Strength Testing Machine Servo Control 300 KN Capacity for sale
