20KW 25KVA Micro CHP Small Power Size CHP Small Cogeneration Mini CHP Small CHP
Continuous Power 20KW
Main Characters
CE certified.
Comprehensive heat insulation to minimize heat loss and with high overall efficiency
CHP inner pipelines are made of full stainless steel material.
Maximum lower the noise level ensure the CHP is available to run in office building and residence site.
Fully open design, maintenance friendly thanks to easy access.
Environmentally friendly design.
Long time R & D and testing ensure high reliability.
Multiple units been installed around the world
CHP Main Specifications
| Model | SP20N | |
| fuel | — | Natural Gas |
| marks | — | Synchro CHP |
| electrical output(KWe) | kVA/kWe | Continuous Power |
| 25/20 | ||
| thermal output(KWt) | kWt | 42.5 |
| electrical efficiency | % | 28.4% |
| thermal efficiency | % | 60.4% |
| overall efficiency | % | 88.4% |
| frequency | Hz | 50 |
| voltage | V | 400/230 |
| gas inlet pressure | kPa | 3-5 |
| dimension (soundproof canopy) | mm*mm*mm | 1800*780*1020 |
| net weight | kgs | 700 |
| NG consumption | m3/kW.h | 0.357 |
| standard type-db(A)@7m | — | 57 |
| Certificate | — | CE |
| water-water heat exchanger | — | SWEP |
| water-exhaust heat exchanger | — | designed by our own factory/made of full stainless steel |
| gas filter | — | Madas |
| zero regulator | — | Maxitrol |
| solenoid valve | — | JL |
| gas pressure gauge | — | Dungs |
| Lambda auto control | — | YES |
| catalyst converter | — | With |
| NOx and CO | — | below 50mg/Nm3 @5% O2 |
| MCB | — | ABB |
| GCB | — | ABB |
For more information about each CHP, please consult with your sales representative.Thanks.
20KW Natural Gas CHP On-site Picture
