120 KW Heating Capacity Constant Water Temperature Heat Pump for Swimming Pool

TRT Air Source Swimming Pool Heat Pumps
Model		TRT-100PHP	TRT-120PHP	TRT-150PHP	TRT-200PHP	TRT-250PHP	TRT-300PHP
	Body size(LWH)	15006901160	15006901160	15078571611	185010001950	200011002080	200011002080
	Compressor	CopelandZW61KA*2	CopelandZW72KA*2	CopelandZW79KA*2	CopelandZW61KA*4	CopelandZW72KA*4	CopelandZW79KA*4
	Refrigerant	R407C/2.1kg*2	R407C/2.5kg*2	R407C/3kg*2	R407C/2.1kg*4	R407C/2.5kg*4	R407C/3.0kg*4
	Power Supply	380V/50Hz	380V/50Hz		380V/50Hz	380V/50Hz	380V/50Hz
	Condenser
	Condenser	2-φ12.7*20	2-φ19*17	2-φ19*17	4-φ19*15	4-φ19*17	4-22*17
	Evaporator	2-650*1260	2-650*1260	2-650*1260	2-900*1500	2-900*1700	2-900*1700
	Evaporator	U-2/φ9.52/25U Pipe	U-3/φ9.52/25U Pipe	U-3/φ9.52/25U Pipe	V-3/φ9.52/25U Pipe	V-3/φ9.52/25U Pipe	V-3/φ9.52/25U Pipe
	Gas-liquid separator	KFR120WLG-A*2	KFR120WLG-A*2	KFR120WLG-A*2	KFR120WLG-A*4	KFR120WLG-A*4	KFR120WLG-A*4
	Four-way Valve	SHF-20A-46*2	SHF-20A-46*2	SHF-20A-46*2	SHF-20A-46*4	SHF-20A-46*4	SHF-20A-46*4
	Expansion Valve	3.2*2	3.2*2	3.2*2	3.2*4	3.2*4	3.2*4
	AC contactor	(220V-25A)*2	(220V-32A)*2	(220V-32A)*2	(220V-25A)*4	(220V-32A)*4	(220V-32A)*4
	Motor/ Fan Blade	YWF.A6S-550S-5DIA00*2	YWF.A6S-550S-5DIA00*2	YWF.A6S-550S-5DIA00*2	YWF.A6S-600S-5DIA00*2	YWF.A6S-630S-5DIA00*2	YWF.A6S-630S-5DIA00*3
	Controller	Double System	Double System	Double System	Four System	Four System	Four System
	Low Pressure Switch	0.05/0.15MPa	0.05/0.15MPa	0.05/0.15MPa	0.05/0.15MPa	0.05/0.15MPa	0.05/0.15MPa
	High Pressure Switch	2.4/3.0MPa	2.4/3.0MPa	2.4/3.0MPa	2.4/3.0MPa	2.4/3.0MPa	2.4/3.0MPa
	Power Line	310mm2+24mm2	310mm2+24mm2	310mm2+24mm2	316mm2+26mm2	316mm2+26mm2	316mm2+26mm2
	Packing	Polywood Packing	Polywood Packing	Polywood Packing	Polywood Packing	Polywood Packing	Polywood Packing
parameters	Rated Heating Capacity(kW)	42	46	56	78	96	115
	Input Power(kW)	7.2	8.4	10.8	14.4	17	22
	Rated Current(A)	16	18	20.7	32	36	42
	COP	5.83	5.48	5.19	5.42	5.65	5.23
	Rated outlet water temperature(℃)	28	28	28	28	28	28
	Max outlet water temperature(℃)	40	40	40	40	40	40
	Water Flow (L/H)	18056	19775	24075	33532	41271	49439
	Waterproof Grade	IPX4	IPX4	IPX4	IPX4	IPX4	IPX4
	Anti-electric shock Rate	I	I	I	I	I	I
	Noise(dB(A))	≤66	≤68	≤68	≤68	≤72	≤75
	Net Weight/ Gross Weight(kg)	280/295	322/350	372/412	482/532	582/642	700/ 760

Description:

TRT Pool Heat Pump provides the maximum energy efficiency and reliability. Working efficiently, the heat pump units absorb another 6 times of free heat from the ambient environment, and transfer it to the pool water, which makes the heating process ecological and cost saving.
