| Categories | Laser Chuck |
|---|---|
| Brand Name: | Lingman |
| Model Number: | G360J-110 |
| Place of Origin: | Changzhou, Jiangsu, China |
| MOQ: | 1 set |
| Price: | USD 2800-3400/set |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 500 sets per month |
| Delivery Time: | 15-20 work days |
| Packaging Details: | Wood carton |
| Product name: | Laser Chuck |
| Jaw stroke: | 110mm |
| Clamping range: | 3-110mm |
| Central height: | 230mm |
| Maximum clamping force: | 0.8KN |
| Allowable pressure: | 0.25-0.9MPa |
| Limit speed: | 200r/min |
| Rotational inertia: | 1.44kg.㎡ |
| Rotating part weight: | 66kg |
| Whole weight: | 116 |
| Company Info. |
| Lingman Machinery Technology (Changzhou) Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
1. Descripition
Our laser chuck is pneumatic type and is mainly used in laser pipe
cutting machine, plasma cutting machine and welding machine. It can
support different shapes of pipes, such as round pipe, square pipe,
rectangular pipe, L-shape pipe and H-shape pipe. It improves the
cutting accuracy, rotation accuracy and repeated positioning
accuracy, compared with traditional chuck. The application of laser
chuck makes laser cutting more efficient and quickly.
It can realize quick clamping and loosening by rotating air intake
from the side, disconnet the air source before working. It is
controlled by switching single and double cylinders, which produces
differentc clamping forces, which has more advantages of clamping
thin-walled tubes and heavy-duty pipes. Becaus of the long length
of the parts processed by the cutter, the main chuck used as the
head position of laser cutting and feed chuck matched with it are
usually installed in pairs on the machine.This penumatic chuck is
widely used in special laser pipe cutters and other pipe processing
machine system.
2. Performance Parameters
| G360J-110 |
| 110mm |
| 0.8KN |
| 0.25-0.9MPa |
| 200r/min |
| 3-110mm |
| 230mm |
| 1.44Kg.m2 |
| 66kg |
| 116kg |
3. Dimensions
| Specifications | A | B | B1 | C | D | E | F | G | H | I | R | S |
| G360J-110 | 320 | 230 | 435 | 447.5 | 220 | 196 | 270 | 197.5 | 110 | 122 | 12-M8 | 14 |
4. Advantages
| a. Full stroke design |
| b. Wide range of applications, diversification of processing profiles |
| c. High repetitive positioning accuracy |
| d. Low maintenance cost, long service life |
e. Multiple configurations are available |
5. Our Service
1.We are the direct factory with good price and fast lead time.
2.Professional design team work with you.
3.Professional QC team to guarantee the high quality.
4.Providing OEM & ODM service.
6. FAQ
Q: What parameters should we offer us for proper quotation?
A: Application, dimension, quantity, packing requirements.
Q:What's your advantages?
A:Honest business with competitive price and professional service on export process.
Q: Can we visit your company to inspect products before delivery?
A: You are welcome to visit our company to inspect us and our
products.
Q:What's your lead time?
A: Within 15-35 days after confirming the order.
Q: What are your payment terms?
A: T/T, L/C, West Union, Paypal, etc.
