| Categories | Android Panel PC |
|---|---|
| Brand Name: | ITD/OEM |
| Model Number: | ITD10PPCT5FJ2 |
| Certification: | CE, FCC, RoHS |
| Place of Origin: | China |
| MOQ: | 1PCS |
| Price: | TBA |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 10000PCS/Month |
| Delivery Time: | 15-20 Business Days |
| Packaging Details: | 1-5pcs/CTN, Safe, Firm, suitable for international shipping |
| Native resolution: | 1024x768 |
| Brightness: | 350nits |
| Processor: | ARM RK3288, RK3399 Android 9/10/11,Ubuntu |
| touch panel: | capacitive |
| optional: | 4G, BT, WIFI |
| I/O: | USB, COM, HDMI, Audio, LAN, DC 12V input |
| Operating Temperature: | -20~70℃ |
| Storage Temperature: | -20~70℃ |
| Material: | Steel Housing |
| MTBF: | 50000hours |
| Company Info. |
| Shenzhen ITD Display Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
10" open frame panel PC ARM based RK3288 Androd 9 Linux Ubuntu 18.04
FEATURES
• Flexible, reliable, and ruggedized for open platform HMI/SCADA
• Energy-efficient and fan-less HMI Systems
• Low-cost solution with high cost-efficient
• All steel construction designed for harsh and industrial
environments
• Flexible, easy configuration and integration
• CE, FCC, RoHS Compliance
OPTIONALS
| • Anti-Glare / Anti-Reflective Tempered Glass | • High Brightness, Optical Bonding |
| • Resistive, IR, SAW, PCAP, SLW | • WIFI, 3G, 4G |
| • Web camera, Speakers, RFID, NFC, Fingerprint, QR Reader, Thermal printer, GPS etc. | • DC9-36V input, AC100-240V input |
DISPLAY
| Panel | Cell Type/Glass Surface | TFT |
| Size/ Aspect Ratio | 10.4”/4:3 | |
| Active Area/ Pixel Pitch | 211.2(W) x 158.4(H)mm/0.297 × 0.20625mm | |
| Native Resolution/ Colors | 1024 x 768/262K/16.7M | |
| Brightness/ Contrast | 350cd/㎡/900:1 | |
| Response Time/ Viewing Angle(Typical) | 16ms/75/75/75/75 | |
| Light Source | LED Backlight with 50000Hours’Lifetime |
SYSTEM
| Item | Android Solution | ||
| CPU | ARM Quad Core Cortex-A17, 1.8GHz | ||
| Chipset | RK3288(RK3399 optional) | ||
| Memory | 2GB; 4GB Optional | ||
| Storage | 8GB: 16GB/32GB/64GB Optional | ||
| Graphics | Supports max. 4K resolution | ||
| I/O | 1 × HDMI; 2 × USB Max. 4× USB; 1 × USB OTG(Optional); 2 × COM; 1 × TF Card Slot Support 8~128GB | ||
| LAN | 1 x 10/100/1000Mbps Ethernet | ||
| OS | Android 9, Linux Ubuntu 18.04 |
GENERAL
| Power | Input Voltage | DC 12V 2.0 |
| Operation/Power Saving | 15~30W | |
| Environment Considerations | Operating Temperature | -10~60℃ (-20~70℃ optional) |
| Storage Temperature | -20~70℃ | |
| Relative Humidity | 10%~90% |


|
