Model Name: | LS058C0010F |
Diagonal Size: | 5.8" |
Panel Type: | Oxide TFT-LCD, CELL, FOG |
Resolution: | 1080(RGB)×2280 434PPI |
Pixel Format: | RGB Vertical Stripe |
Active Area: | 63.072(W)×133.152(H) mm |
Used for: | Mobile Phone |
Color Depth: | 16.7M 80%NTSC |
Glass Thickness: | 0.15+0.15 mm |
Work Mode: | New mode 2, Normally Black, Transmissive |
Company Info. |
Shenzhen Yongsheng Innovation Technology Co., Ltd |
Verified Supplier |
View Contact Details |
Product List |
LS058C0010F 5.8 inch LCD Panel Display 1080*2280 LCD Screen
LS058C0010F LCD Panel Product details :
Brand | Sharp |
Model P/N | LS058C0010F |
Diagonal Size | 5.8" |
Panel Type | Oxide TFT-LCD, CELL, FOG |
Resolution | 1080(RGB)×2280 434PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 63.072(W)×133.152(H) mm |
Bezel Opening | - |
Outline(mm) | 64.82 × 138.99× 0.61 (H×V×D) |
Treatment | Hard coating (3H) |
Luminance | 0 cd/m² |
Contrast Ratio | 1300 : 1 (Typ.) (TM) |
Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
Response | 25 (Typ.)(Tr+Td) ms |
Good View at | Symmetry |
Work Mode | New mode 2, Normally Black, Transmissive |
Glass Thickness | 0.15+0.15 mm |
Transmissivity | 3.9% (Typ.) |
Color Depth | 16.7M 80%NTSC |
Backlight | No B/L |
Mass | 11.0g (Typ.) |
Used for | Mobile Phone |
Refresh Rate | 60Hz |
Touchscreen | In-Cell Touch, I²C |
Driver IC list | Built-inCOGTD4105 |
Signal Type | MIPI (4 data lanes), 30 pins Connector |
Voltage Supply | 1.8/5.8/-5.8V (Typ.)(IOVCC/VSP/VSN) |
Max. Ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
